T1 Coated E-White
T1 Coated E-White
*Order dispatch within 3-7 days.
Download: T1 V2.1 Assembly Manual
View full detailsCPU Clearance
Maximum Height 48mm
AXP90-X47 CU
Alpenfohn Black Ridge
*Standard AIO(None LCD/RGB)
AXP90-X47 CU
ID-COOLING IS-47-XT
*Standard AIO(None LCD/RGB)
ID-COOLING IS-50X
NZXT Kraken 240
*Standard 120/240 AIO (w/ 12015)
Black Ridge with Top 12015
NZXT Kraken Elite
*Most 120/240 AIO (w/ 12015)
AXP-120-X67
NH-L12 GS Edition
*Most 120/240 AIO (w/ 12015)
Scythe Big Shuriken 3
NOCTUA NH-L12S
*120/240 AIO (w/ 12015)
NOCTUA NH-L12S
AXP-120-X67 with 12025
*120/240 AIO (w/ 12015)
NOCTUA NH-L12S
AXP-120-X67 with 12025
*120/240 AIO (w/ 12015)
NH-L12S with 12015
AXP-120-X67 with 12025
*120/240 AIO (w/ 12015)
NOCTUA NH-L12
*120/240 AIO (w/ 12015)
*Side Radiator for Custom Loop
and more...
GPU Clearance
140 × 325 × 20(mm)
NVIDIA GeForce RTX4090 FE
NVIDIA GeForce RTX4080 FE
NVIDIA GeForce RTX3090 FE
NVIDIA GeForce RTX4090 FE
NVIDIA GeForce RTX4080 FE
NVIDIA GeForce RTX3090 FE
AMD RX 7900XTX
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA RTX 4000 Ada
NVIDIA RTX 4000 Ada
NVIDIA RTX 4000 Ada
NVIDIA RTX 4000 Ada
and more...
CPU Clearance
Maximum height 48mm
AXP90-X47 CU
Alpenfohn Black Ridge
*Standard AIO(None LCD/RGB)
AXP90-X47 CU
ID-COOLING IS-47-XT
*Standard AIO(None LCD/RGB)
ID-COOLING IS-50X
NZXT Kraken 240
*Standard 120/240 AIO (w/ 12015)
Black Ridge with Top 12015
NZXT Kraken Elite
*Most 120/240 AIO (w/ 12015)
AXP-120-X67
NH-L12 GS Edition
*Most 120/240 AIO (w/ 12015)
Scythe Big Shuriken 3
NOCTUA NH-L12S
*120/240 AIO (w/ 12015)
NOCTUA NH-L12S
AXP-120-X67 with 12025
*120/240 AIO (w/ 12015)
NOCTUA NH-L12S
AXP-120-X67 with 12025
*120/240 AIO (w/ 12015)
NH-L12S with 12015
AXP-120-X67 with 12025
*120/240 AIO (w/ 12015)
NOCTUA NH-L12
*120/240 AIO (w/ 12015)
*Side Radiator for Custom Loop
and more...
GPU clearance
140 x 325 x 20(mm)
NVIDIA GeForce RTX4090 FE
NVIDIA GeForce RTX4080 FE
NVIDIA GeForce RTX3090 FE
NVIDIA GeForce RTX4090 FE
NVIDIA GeForce RTX4080 FE
NVIDIA GeForce RTX3090 FE
AMD RX 7900XTX
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA GeForce RTX3080 FE
NVIDIA GeForce RTX4070 FE
NVIDIA RTX 4000 Ada
NVIDIA RTX 4000 Ada
NVIDIA RTX 4000 Ada
NVIDIA RTX 4000 Ada
and more...
-
Volume & Footprint
9.95 (L)
452.25 (cm²) or 70.1 (in²)
-
Dimension
13.5 × 22 × 33.5 (cm)
5.3 × 8.7 × 13.2 (in)
-
Material
Up to 16mm CNC Machined Aluminum Block, Anodized
Up to 2mm Carbon Steel, Powder Coated -
Shipment Info
2.0 - 2.5 (kg) or 4.4 - 5.5 (lbs)
8 × 30 × 40 (cm) or 3.2 × 11.8 × 15.8 (in)
-
Components Support
Mini-ITX or Deep-ITX
SFX or SFX-L Power Supply (not recommended with AIO)PCIe 4.0 x16 Riser (Included)
Front Power Button (Included)Rear M19 Power Button & Fittings (in Fittings Pack)
10Gbps+ Front USB-C Cable (in T1 Essential Pack)
-
Liquid Cooling Support
46mm Maximum Thickness for 120 / 240AIO & Fans:
2 × 12025 Fan (+ 120AIO)
2 × 12015 Slim Fan (+ 240AIO)
Side Mount 240 or 280 Radiator (not recommended) requires 1-slot GPU and Side Fan Bracket :2 × 120 Fan (+ 240AIO) or 2 × 140 Fan (+ 280AIO)
2024-01 T1 Latest Update Notes
Improved Front Panels
- Added Bracket Brace for V2.1 Side Fan + Radiator on the GPU Side. This feature allows the possibility of dual radiator builds where the second radiator is mounted to the GPU side.
- Updated SFX Bracket, SFX, SFX-L PSU can be installed more securely.
Improved Rear Panels
- The Rear Panel M19 holes are now 19mm through-holes, no longer threaded.
- The GPU Lock Bars from V2.0 have been replaced with GPU Lock Brackets. These brackets allow for better GPU cable (DP, HDMI) clearance compared to the old bars.
- Improved Side Fan Brackets
Backward Compatibility
- For all users who has supported us before, we have not forgotten about you. Parts on the latest 2.1 update is backward compatible with v2.0 T1. If you wish to upgrade to the latest version.
- You can purchase all current T1 components individually by contacting support@formdt1.com. (Shipping calculated separately based on receiving country)
- Old USB-C Kit customers will receive a discounted price, $15, to purchase the official USB-C Cable through support@formdt1.com.
Other Improvements
- Riser Bar Upgraded. (Accessories Coming)
- PCIe Cable Updated. (Silvermix Cable comes with E-White & Silver T1)
Product Brief & Shipping
Quality Guide
We are dedicated in providing the best pricing and value for our products.
After exploring various manufacturing processes, to make the pricing reasonable and cost savings most impactful, some trade-offs had to be made.
Color: Some color variations of the parts that make up the product is standard and expected. In addition, some color variation between products of the same color is normal and expected. Examples of color variation can be viewed in this album.
Surface: Minor surface blemishes are typical and expected, as long as they do not impede the product's functions. However, there is difference between exterior and interior standard:
- Exterior: scratches / dents / blemishes on exterior surfaces larger than 0.5x1cm are covered under the warranty.
- Interior: scratches / dents / blemishes on interior surfaces larger than 2x1cm in size are covered under the warranty.
*Note: The interior surfaces will inevitably show wear and tear by building the product.
Ordering Notes
- Each shipping date has a limited, preset number of products available.
- Only the product options shown at the time of order are available.
- Items in the cart are not reserved, so they may go out of stock while checking out.
- Please ensure your shipping address is complete and accurate. Please notify us of any corrections as soon as possible.
- You will be charged immediately upon completing the checkout process.
- A confirmation email will be sent to you after completing your order. Check your spam folder if you don't see it. Hotmail/MSN/Outlook users: please add support@formdt1.com to your safe senders' list, otherwise emails may not get through.
- All changes to your order, including SKU, quantities, address corrections, or cancellation requests, must be submitted 72 hours before shipping. Otherwise, we cannot make any changes once you order.
- Cancellations requested by the customer are subject to a 4% payment processing fee. Additional foreign exchange fees may apply for payments *not in US dollars.
- Refunds are made to the original payment method and usually take 5-10 business days to process.
- Refunded orders cannot be reversed, and if you cancel and change your mind later, you will need to place a new order.
Shipping Notes
- All items are prepackaged for individual shipping by default, so we cannot combine shipping for multiple items unless stated otherwise.
- The shipping times we provide are only an estimate; actual shipping times may vary and are subject to customs processing or other delays.
- A third party provides tracking numbers to us within a few days of shipping. We will update your order with the tracking number once we have it (usually by the end of your shipping week).
- Tracking may show "Origin Post is Preparing Shipment" or something similar for some time. This is normal, as some shipping methods do not update tracking to indicate the item has been shipped. Tracking should resume updating once the package has reached the destination country and been processed through customs.
- Any import fees/taxes/VAT owed is the recipient's responsibility. Typically, the courier will notify you of any fees due. US customers do not have to pay any import fees.
- A signature is required for delivery. Please be sure that someone is available to receive and sign the package. If not, please coordinate with the courier to pick it up at their office.
- Please note that we cannot change the address or redirect shipments once they have shipped.
- If delivery fails and the package is returned to Asia, we may ask you to pay all or part of the shipping cost to have it reshipped. If, instead, after the package is returned, we may elect to refund the amount less all or part of the original shipping cost plus the 4% payment processing fee.
-
